301.04.0013 Cartridge, Air Dryer Valve
4414 Visualized

301.04.0013 Cartridge, Air Dryer Valve — DAF

301.04.0013

Summary

The 301.04.0013 Air Dryer Valve Cartridge is a high-precision component designed for heavy commercial vehicle brake systems. It features an outside diameter of 148 mm, an inside diameter of 12 mm, and a height of 168 mm to ensure optimal pneumatic filtration and system stability.

EAN Code8683457047150
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Description

The air dryer cartridge is a critical component within the pneumatic braking system, responsible for removing moisture and contaminants from the compressed air stream to protect downstream components. This high-strength component is engineered to maintain consistent air quality, preventing ice formation and corrosion within the heavy commercial vehicle's pneumatic circuits.

301.04.0013 is the OE-equivalent Air Dryer Valve Cartridge used in DAF (878470), HALDEX (78964, 93522), IVECO (42535061, 4731907), KASSBOHRER (82854945650), MAN (81.52102-6146), MERCEDES BENZ (000 429 46 95), SCANIA (1381813, 1393551), and VOLVO (03097369, 20424148, 20546795, 20773824) systems. This part ensures seamless integration with professional-grade braking hardware.

For workshop technicians and fleet managers, regular replacement of the air dryer cartridge is essential to prevent system failures caused by moisture buildup. When performing maintenance on heavy commercial vehicles, ensure the housing is clean and the new cartridge is seated correctly to maintain optimal pressure levels and air purity. This part is designed for easy assembly in professional workshop environments.

Technical Specifications

Outside Diameter (D)148 mm
Inside Diameter (d)12 mm
Height168 mm

Other OEMs

DAF

  • 878470

HALDEX

  • 78964
  • 93522

IVECO

  • 42535061
  • 4731907

KASSBOHRER

  • 82854945650

MAN

  • 81.52102-6146
  • 81521026146

MERCEDES BENZ

  • 000 429 46 95
  • A0004294695

RENAULT TRUCKS

  • 5001826800

SCANIA

  • 1381813
  • 1393551

VOLVO

  • 03097369
  • 20424148
  • 20546795
  • 20773824

Vehicles Used

BrandModelEngine
DAF
HALDEX
IVECO
KASSBOHRER
MAN
MERCEDES BENZ
RENAULT TRUCKS
SCANIA
VOLVO

FAQ

Which vehicle brands are compatible with this cartridge?
This cartridge is compatible with DAF (878470), HALDEX (78964, 93522), IVECO (42535061, 4731907), KASSBOHRER (82854945650), MAN (81.521(one) -6) , MERCEDES BENZ (000 429 46 95), SCANIA (1381813, 1393551), and VOLVO (various codes).
What are the physical dimensions of the 301.04.0 .<...>
The cartridge features an outside diameter of 148 mm, an inside diameter of 12 mm, and a total height of 168 mm.
Is this part suitable for heavy commercial vehicles?
Yes, this component is specifically engineered for heavy commercial vehicle brake systems including trucks and buses.
What is the function of an Air Dryer Valve Cartridge?
It filters moisture and contaminants from the compressed air to ensure the longevity of the pneumatic braking system.
Can I use this as an OEM equivalent for Volvo?
Yes, it serves as an OE-equivalent for several Volvo models using codes such as 20773824, 20546795, 20424148, and 03097369.
