301.03.0084 Complete, Air Dryer Valve
3416 Visualized

301.03.0084 KNORR-BREMSE Complete, Air Dryer Valve

301.03.0084

Summary

●Heater: 24 V ●Port 1: M22x1,5 ●Port 2: M12x1,5 ●Port 21: Ø20,5 ●Pressure: 10 BAR ●Port 22: M16x1,5 VOSS ●Port 23: M22x1,5 ●Port 24: M22x1,5 VOSS ●Port 25: M10X1

EAN Code8699031080550
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Description

The heavy-duty grade materials used in this air dryer valve assembly ensure reliable pneumatic filtration and moisture removal within the brake system. Designed for high-pressure stability, this component plays a critical role in maintaining the air quality and operational integrity of the vehicle's pneumatic circuits.

301.03.0084 is the OE-equivalent of the KNORR-BREMSE I90186, K002740, K002740BRA, K002740N00, K024635N50, K069281, LA 4127, LA 9018 and MERCEDES BENZ 000 430 70 15 air dryer valves used in heavy commercial vehicles. This assembly is specifically engineered to meet the rigorous demands of professional workshop environments and fleet maintenance requirements.

For workshop technicians performing routine maintenance or system overhauls, this unit provides a precise fit with its specific port configurations including M22x1,5 and M16x1,5 VOSS connections. It is essential to verify the 24 V heater compatibility and the 10 BAR pressure rating during installation to ensure optimal performance within the braking system architecture.

Regular inspection of the air dryer components is recommended to prevent moisture buildup in the pneumatic lines. This part ensures that the air supply remains dry and clean, protecting downstream components from corrosion and freezing during operation.

Technical Specifications

Heater24 V
Port 1M22x1,5
Port 2M12x1,5
Port 21Ø20,5
Pressure10 BAR
Port 22M16x1,5 VOSS
Port 23M22x1,5
Port 24M22x1,5 VOSS
Port 25M10X1

Other OEMs

KNORR-BREMSE

  • I90186
  • K002740
  • K002740BRA
  • K002740N00
  • K024635N50
  • K069281
  • LA 4127
  • LA 9018
  • LA4127
  • LA9018

MERCEDES BENZ

  • 000 430 70 15
  • 0004307015
  • A0004307015

Related Products

Repair Kits

Products Used in

Vehicles Used

BrandModelEngine
KNORR-BREMSE
MERCEDES BENZ

FAQ

Which OEM numbers is this part compatible with?
This product is compatible with KNORR-BREMSE codes I90186, K002740, K002740BRA, K002740N00, K024635N50, K069281, LA 4127, LA 9 de 9 (LA 9018) and MERCEDES BENZ 000 430 7 de 7 (7/15).
What is the voltage requirement for the heater?
The unit is designed for heavy commercial vehicle systems requiring a 24 V power supply for the integrated heater function.
What are the specific port dimensions for installation?
The technical specifications include Port 1 (M22x1,5), Port 2 (M12x1,5), Port 21 (Ø20,5), Port 22 (M16x1,5 VOSS), Port 23 (M22x1,5), Port 24 (M22x1,5 VOSS), and Port 25 (M1ox).
Is this part suitable for heavy commercial vehicles?
Yes, it is engineered specifically for heavy commercial vehicle brake systems such as those found in trucks and buses.
What is the maximum operating pressure for this valve?
The component is designed to operate reliably within a pressure rating of up to 10 BAR.
