301.03.0052 KNORR-BREMSE Complete, Air Dryer Valve
301.03.0052
Summary
●Heater: 24 V ●Port 1: M22x1,5 ●Port 21: M22x1,5 ●Pressure: 12 BAR ●Port 22: M12x1,5 ●Port 4/23: M12x1,5
| EAN Code | 8699031080154 |
|---|
Ready to Order
Compatible OEM Codes
- KNORR-BREMSE LA 8286 II39752FN50 II39752FAT000 II39752FAT II39752F05T II39752F000 II39752F00 II37715AT II37715 I98286
Description
The VADEN ORIGINAL 301.03.0052 is a high-quality component designed for optimal pneumatic performance in heavy commercial vehicle brake systems. This complete air dryer valve ensures the removal of moisture and contaminants from the compressed air to maintain system reliability.
This product is a direct equivalent to the KNORR-BREMSE I98286, II37715, II37715AT, II39752F00, II39752F000, II39752F05T, II39752FAT, II39752FAT000, II39752FN50, and LA8286 models. The 301.03.0052 is the OE equivalent of the KNORR-BREMSE Complete, Air Dryer Valve used in KNORR-BREMSE systems. It is engineered to meet strict technical requirements for pressure and port dimensions.
The unit features a 24 V heater and specific port configurations including M22x1,5 for ports 1 and 21, and M12x1,5 for ports 22 and 4/23. It is designed to operate effectively at a pressure of 12 BAR. Technicians should ensure that all connections are secure and check the port threads during installation to prevent air leaks.
Maintaining the air dryer is critical for preventing ice formation and component damage within the pneumatic system. Regular inspection of the filter element and moisture levels is recommended to ensure long-term durability of the braking hardware.
This product is a direct equivalent to the KNORR-BREMSE I98286, II37715, II37715AT, II39752F00, II39752F000, II39752F05T, II39752FAT, II39752FAT000, II39752FN50, and LA8286 models. The 301.03.0052 is the OE equivalent of the KNORR-BREMSE Complete, Air Dryer Valve used in KNORR-BREMSE systems. It is engineered to meet strict technical requirements for pressure and port dimensions.
The unit features a 24 V heater and specific port configurations including M22x1,5 for ports 1 and 21, and M12x1,5 for ports 22 and 4/23. It is designed to operate effectively at a pressure of 12 BAR. Technicians should ensure that all connections are secure and check the port threads during installation to prevent air leaks.
Maintaining the air dryer is critical for preventing ice formation and component damage within the pneumatic system. Regular inspection of the filter element and moisture levels is recommended to ensure long-term durability of the braking hardware.
Technical Specifications
| Heater | 24 V |
|---|---|
| Port 1 | M22x1,5 |
| Port 21 | M22x1,5 |
| Pressure | 12 BAR |
| Port 22 | M12x1,5 |
| Port 4/23 | M12x1,5 |
Other OEMs
KNORR-BREMSE
- LA8286
- LA 8286
- II39752FN50
- II39752FAT000
- II39752FAT
- II39752F05T
- II39752F000
- II39752F00
- II37715AT
- II37715
- I98286
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| KNORR-BREMSE |
FAQ
What are the compatible OEM reference numbers for this part?
This product is compatible with the following references: I98286, II37715, II37715AT, II39752F00, II39752F000, II39752F05T, II39752FAT, II39752FAT000, II39752FN50, LA8286.
What are the technical specifications for the ports?
The unit features Port 1 and Port 21 with M22x1,5 threads, while Port 22 and Port 4/23 utilize M12x1,5 threads.
Does this component require a specific voltage?
Yes, this complete air dryer valve is designed with a 24 V heater for compatibility with standard heavy commercial vehicle electrical systems.
What is the maximum operating pressure?
The component is engineered to operate at a pressure of up to 12 BAR within the pneumatic brake system.
How can I identify if this part is correct for my system?
Check your existing part's port sizes (M22x1,5 and M12x1,5) and ensure the voltage matches your vehicle's electrical system (typically 24V).
