301.03.0018 KNORR-BREMSE Complete, Air Dryer Valve
301.03.0018
●Heater: 24 V ●Port 1: M22x1,5 ●Port 21: M22x1,5 ●Pressure: 12,5 BAR ●Port 22: M12x1,5 ●Port 4/23: M12x1,5
| EAN Code | 8699031079813 |
|---|
Description
The heavy-duty grade component serves a critical role in the pneumatic brake system by ensuring clean, dry air reaches the vehicle's braking components. This Complete, Air Dryer Valve is engineered to manage moisture and pressure effectively within the air circuit to maintain optimal braking performance.
301.03.0018 is the OE-equivalent of the KNORR-BREMSE II19486, II19486AT, II19486N00, II19486N50, and LA 8222 components used in DAF, IVECO, and KNORR-BREMSE heavy commercial vehicle systems. It also serves as a direct replacement for DAF 1518674 and IVECO 8160467 to ensure seamless integration with existing pneumatic architectures.
Workshop technicians should note the specific port configurations: Port 1 and Port 21 utilize M22x1,5 threading, while Port 22 and Port 4/23 are designed for M12x1,5 connections. The unit is rated for a working pressure of 12,5 BAR and includes a 24 V heater to prevent freezing in low-temperature environments. Regular inspection of the port seals and air quality is recommended during routine maintenance cycles.
Technical Specifications
| Heater | 24 V |
|---|---|
| Port 1 | M22x1,5 |
| Port 21 | M22x1,5 |
| Pressure | 12,5 BAR |
| Port 22 | M12x1,5 |
| Port 4/23 | M12x1,5 |
Other OEMs
DAF
- 1518674
IVECO
- 8160467
KNORR-BREMSE
- II19486
- II19486AT
- II19486N00
- II19486N50
- LA 8222
- LA8222
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Engine |
|---|---|---|
| DAF | ||
| IVECO | ||
| KNORR-BREMSE |
