301.03.0007 DAF Complete, Air Dryer Valve
301.03.0007
Summary
●Heater: 24 V ●Port 1: M22x1,5 ●Port 21: M22x1,5 VOSS ●Pressure: 9,8 BAR ●Port 22: M16x1,5 VOSS ●Port 4/23: M16x1,5 VOSS
| EAN Code | 8699031079707 |
|---|
Ready to Order
Compatible OEM Codes
- KNORR-BREMSE LA 8206 LA 6248 II19375N52 II19375N50 II19375AT II19375115 II19375 I68206
- MERCEDES BENZ 001 431 01 15
- DAF 1285548
Description
This high-strength component serves as a vital part within the pneumatic brake system, ensuring the efficient removal of moisture and contaminants from compressed air. Designed for heavy commercial vehicle applications, it maintains stable air pressure and protects downstream components from damage.
The 301.03.0007 is the OE equivalent of the DAF 1285548 and is compatible with Mercedes-Benz 0014310115, KNORR-BREMSE 68206, 19375, 19375115, 19375AT, 19375N50, 19375N52, LA6248, and LA8206 systems. This part provides reliable performance for professional workshop technicians and fleet managers managing heavy-duty fleets.
The assembly features specific port configurations including Port 1 (M22x1,5), Port 21 (M22x1,5 VOSS), Port 22 (M16x1,5 VOSS), and Port 4/23 (M16x1,5 VOSS) to ensure a precise fit within the air treatment system. It is engineered to operate effectively at a pressure of 9.8 BAR in a 24 V environment.
Regular inspection of the air dryer valve assembly is essential to prevent moisture buildup in the braking system. Maintenance should be performed by qualified service technicians to ensure optimal vehicle safety and system longevity.
The 301.03.0007 is the OE equivalent of the DAF 1285548 and is compatible with Mercedes-Benz 0014310115, KNORR-BREMSE 68206, 19375, 19375115, 19375AT, 19375N50, 19375N52, LA6248, and LA8206 systems. This part provides reliable performance for professional workshop technicians and fleet managers managing heavy-duty fleets.
The assembly features specific port configurations including Port 1 (M22x1,5), Port 21 (M22x1,5 VOSS), Port 22 (M16x1,5 VOSS), and Port 4/23 (M16x1,5 VOSS) to ensure a precise fit within the air treatment system. It is engineered to operate effectively at a pressure of 9.8 BAR in a 24 V environment.
Regular inspection of the air dryer valve assembly is essential to prevent moisture buildup in the braking system. Maintenance should be performed by qualified service technicians to ensure optimal vehicle safety and system longevity.
Technical Specifications
| Heater | 24 V |
|---|---|
| Port 1 | M22x1,5 |
| Port 21 | M22x1,5 VOSS |
| Pressure | 9,8 BAR |
| Port 22 | M16x1,5 VOSS |
| Port 4/23 | M16x1,5 VOSS |
Other OEMs
DAF
- 1285548
KNORR-BREMSE
- LA8206
- LA6248
- LA 8206
- LA 6248
- II19375N52
- II19375N50
- II19375AT
- II19375115
- II19375
- I68206
MERCEDES BENZ
- A0014310115
- 0014310115
- 001.431.0115
- 001.431.01.15
- 001 431 0115
- 001 431 01 15
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| DAF | |||
| KNORR-BREMSE | |||
| MERCEDES BENZ |
FAQ
What are the compatible OEM references for this part?
This part is compatible with the following references: DAF 1285548, KNORR-BREMSE I68206, II19375, II19375115, II19375AT, II19375N50, II19375N52, LA6248, LA8206 and MERCEDES BENZ 0014310115.
Which vehicle makes use this air dryer valve?
This component is designed for use in heavy commercial vehicle systems from brands such as DAF and Mercedes-Benz.
What are the technical specifications of the ports?
The unit features Port 1 with M22x1,5 and Port 21 with M22x1,5 VOSS. Ports 22 and 4/23 are equipped with M16x1,5 VOSS connections.
Is this part suitable for a 24V electrical system?
Yes, this complete air dryer valve is specifically designed to operate within a 24 V electrical environment.
How can I identify if the air dryer needs replacement?
Technicians should look for signs of moisture buildup or pressure drops within the pneumatic brake system as indicators for replacement.
