301.02.0064 Complete, Air Dryer Valve — MAN

The heavy-duty air dryer valve assembly is a critical component within the pneumatic braking system, designed to ensure clean and dry air delivery to the vehicle's braking circuits. This component provides essential moisture separation to protect sensitive pneumatic systems from corrosion and ice formation, maintaining consistent pressure levels during operation.

301.02.0064 is the OE-equivalent of the MAN 81.52102-6020, 81.52102-6022, 81.52102-6024, 81.52102-6037, 81.52102-6060, 81.52102-6097, 81.52102-6101, and 81.52102-6107 air dryer valve used in MAN, DAF, and NEOPLAN heavy commercial vehicles. It is also fully compatible with WABCO systems under reference 432 410 113 0 and DAF reference 1517967.

For workshop technicians and fleet managers, this assembly features specific port configurations including Port 1 (M22x1,5), Port 21 (M22x1,5 VOSS), and Port 22 (M16x1,5 VOSS). It is engineered to operate at a standard pressure of 12,5 BAR, ensuring seamless integration into existing braking infrastructures for trucks and buses. Regular inspection of the filter elements within the air dryer unit is recommended to maintain optimal system pneumatic integrity.
