301.01.0016 Unloader Valves — MERCEDES BENZ

301.01.0016

Summary

●Port 1: M22x1,5 ●Port 4: - ●Port 21: M22x1,5 ●Port 23: - ●Plugged: OK ●Cut-Out Pressure: 7,3 BAR / 0,2 BAR ●Inflation Valve: OK ●Recycle Valve: OK ●Port 22: FITTING/KÖR TAPA

EAN Code8683457011014
Ready to Order
Get Information

Description

The technical functionality of this unloader valve ensures precise pneumatic control within the brake system, maintaining stable pressure levels for heavy commercial vehicle operations. Designed with high-strength components, it provides reliable performance under demanding service conditions by managing air flow and pressure regulation effectively.

301.01.0016 is the OE equivalent of the MERCEDES BENZ 001 431 22 06 and IVECO 04784409 used in MERCEDES BENZ, IVECO, MAN, and DAF vehicles. This component is engineered to meet the exact specifications required for seamless integration into complex pneumatic braking architectures.

Workshop technicians should note the specific port dimensions, featuring M22x1,5 connections on Port 1 and Port 21, to ensure correct assembly and prevent leakage. Regular maintenance checks of the cut-out pressure settings and inflation valve functionality are recommended to maintain optimal system responsiveness during heavy-duty transport tasks.

This part is suitable for a wide range of heavy commercial applications including trucks and buses that require precise unloader valve performance for air system stability.

Technical Specifications

Port 1M22x1,5
Port 4-
Port 21M22x1,5
Port 23-
PluggedOK
Cut-Out Pressure7,3 BAR / 0,2 BAR
Inflation ValveOK
Recycle ValveOK
Port 22FITTING/KÖR TAPA

Other OEMs

DAF

  • 0513733
  • 1518279

EVOBUS

  • 8283699000

IVECO

  • 02516892
  • 02516923
  • 02516973
  • 02521211
  • 02808514
  • 04700994
  • 04775735
  • 04775736
  • 04775737
  • 04775738
  • 04784409
  • 04826204
  • 42085760
  • 42085762
  • 42470088
  • 500005822

MAN

  • 81.52101-6022
  • 81.52101-6073
  • 81.52101-6081
  • 81.52101-6235
  • 81.52101-6281
  • 81521016022
  • 81521016073
  • 81521016081
  • 81521016235
  • 81521016281

MERCEDES BENZ

  • 001 431 22 06
  • 001 431 22 26
  • 001 431 41 06
  • 001 431 42 06
  • 001 431 43 06
  • 001 431 82 06
  • 001 431 99 06
  • 002 431 35 06
  • 002 431 60 06
  • A0014312206
  • A0014312226
  • A0014314106
  • A0014314206
  • A0014314306
  • A0014318206
  • A0014319906
  • A0024313506
  • A0024316006

O&K

  • 4510390

RENAULT TRUCKS

  • 5000241771

TEREX

  • 46131340

WABCO

  • 975 303 447 0
  • 9753034470

Related Products

Vehicles Used

BrandModelEngine
DAF
EVOBUS
FAUN
FREIGHTLINER
GOLDHOFER
IKARBUS
IRISBUS
IVECO
KENWORTH
KRONE
LEYLAND
MACK
MAN
MAN NEOPLAN
MERCEDES BENZ
MERITOR
NEOPLAN
O&K
OTOKAR
PETERBILT
RENAULT TRUCKS
SCANIA
STEYR
TEREX
VOLVO
WABCO

FAQ

What are the compatible OEM numbers for this unloader valve?
This part is compatible with several OEM numbers including MERCEDES BENZ 001 431 22 06, IVECO 4784409, MAN 81.52101-6281, DAF 1518279, and WABCO 9753034470.
Which vehicle brands can use this part?
This component is designed for heavy commercial vehicles from brands such as MERCEDES BENZ, IVECO, MAN, DAF, RENAULT TRUCKS, and SCANIA.
What are the technical port specifications?
The unit features Port 1 with M22x1,5 threading and Port 21 with M22x1,5 threading, ensuring precise fitment within the pneumatic system.
Does this part include an inflation valve?
Yes, this unloader valve is equipped with a functional inflation valve and recycle valve to support standard brake system operations.
Is this part suitable for heavy-duty trucks?
Yes, it is specifically designed for heavy commercial vehicle brake systems to provide consistent pressure regulation and durability.
